An automated robot designed to work alongside human workers
| MOQ: | 1 |
| Giá bán: | Negotiations |
| bao bì tiêu chuẩn: | Bao bì tiêu chuẩn quốc tế cho vận chuyển |
| Thời gian giao hàng: | 30 ngày |
| Phương thức thanh toán: | L/C,T/T, Công Đoàn Phương Tây |
| khả năng cung cấp: | 300 bộ mỗi năm |
Thông tin chi tiết
Nguồn gốc
Thượng Hải
Hàng hiệu
Waylead
Chứng nhận
/
Số mô hình
WP-30
Tài liệu
Tốc độ xếp pallet được thiết kế:
8-12 lần/phút (tùy sản phẩm)
Kích thước pallet tương thích tối đa:
1200mm*1000mm
Phương pháp đặt pallet:
Hướng dẫn sử dụng, một bên trái và một bên phải
Tổng công suất xếp hàng:
3,5kw
Kích thước đơn vị chính:
L1732mm*W1200mm*H2490mm
Nguồn điện:
220V±10%, 50Hz±5%, điện áp điều khiển là DC 24V;
Màu đơn vị chính:
Màu xám bạc
Làm nổi bật:
automated robot for human collaboration
,robot palletizing system with automation
,industrial robot for warehouse palletizing
Mô tả sản phẩm
An automated robot designed to work alongside human workers
Collaborative Palletizing Robot: An automated robot designed to work alongside human workers, capable of performing repetitive tasks such as palletizing.
Technical Specifications
| Model | WP-30 | WP-50 |
|---|---|---|
| Designed arm span | 1680mm | 1780mm |
| Designed palletizing speed | 8-12 times/minute (depending on product) | 6-8 times/minute (depending on product) |
| Maximum compatible pallet size | 1200mm*1000mm | 1200mm*1100mm |
| Pallet placement method | Manual, one on the left and one on the right | Manual, one on the left and one on the right |
| Robot load | 25KG | 45KG |
| Palletizing height (Maximum palletizing height) | 2350mm | 2450mm |
| Main unit dimensions | L1732mm*W1200mm*H2490mm | L1732mm*W1300mm*H2615mm |
| Logistics wooden box dimensions | L2200mm*W1450mm*H1900mm | L2250mm*W1450mm*H1900mm |
| Total palletizing power | 3.5KW | 3.5KW |
| Power supply | 220V±10%, 50Hz±5%, control voltage is DC 24V | 220V±10%, 50Hz±5%, control voltage is DC 24V |
| Air supply | 0.5～0.7Mpa Reference gas consumption: 240-460 L/min | 0.5～0.7Mpa Reference gas consumption: 240-460 L/min |
| Weight | Approximately 600 kg | Approximately 650 kg |
| Noise level | <80 decibels | <80 decibels |
| Main unit color | Silver gray | Silver gray |
Application Range
- Boasting a maximum load capacity of 30 kg (note: load capacity decreases as arm span extends), this robotic solution delivers unrivaled flexibility for diverse industrial tasks.
- Featuring user-friendly graphical programming, operators can master full operation in just 5 minutes—no advanced coding skills required.
- It supports simultaneous palletizing of two box types (A & B) and is preloaded with up to 60 customizable palletizing recipes, streamlining mixed-product workflows.
- With a compact footprint and flexible mobility, the robot fits seamlessly into tight production spaces and can be repositioned effortlessly as your needs change.
Safety is prioritized too: the system operates reliably without the need for additional guardrails, cutting installation costs and saving floor space.
Complete Packaging Machine Range
Our comprehensive packaging solutions include VFFS machines, flow wrapping machines, heat shrink packaging, pouch packing machines, and complete automated packaging lines with weight inspection, metal detection, carton packing, sealing, coding, and palletizing systems.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a manufacturer, providing quality products at factory price. Welcome to visit us!
What quality guarantee or warranty do you provide?
We provide high-quality machines with a 3-year warranty and lifetime technical support.
When can I get the machine after payment?
Delivery time depends on the specific machine model ordered.
How do you provide technical support?
24/7 support via phone, email, or messaging platforms; installation guides and videos; overseas engineering services available.
How does your after-sales service work?
Machines are pre-adjusted before shipment with free training available. Lifetime technical support provided via multiple communication channels.
How about spare parts?
We provide a comprehensive spare parts list for reference.
Can you help with custom design requirements?
Customized design available with our experienced mechanical engineers.
Can you help analyze and design machines for new product samples?
Yes, our technical department can analyze, design, and test new products you provide.
How do I start an order?
30% deposit after signing contract, production arrangement, pre-shipment testing and inspection, balance payment before shipment.
Can you send product catalog and price list?
Electronic catalog available. Please consult us for specific product pricing.
Can I visit your factory?
Yes, welcome to visit our factory at Room 304, Wanchuangfang, No.155 Anzhi Road, Jiading District, Shanghai, China.
